How to Pass IEEE Ethernet Compliance Tests Time Domain Reflectometry with DP83867 and DP83869 View all 23ĭP83867E/IS/CS Robust, High Immunity, Small Form Factor 10/100/1000 Ethernet Physical Layer Transceiver datasheet (Rev. Wake-on-LAN can be used to lower system power consumption. It has low latency and provides IEEE 1588 Start of Frame Detection.ĭesigned for low power, the DP83867 consumes only 457 mW under full operating power.
The DP83867 provides precision clock synchronization, including a synchronous Ethernet clock output. This device interfaces directly to the MAC layer through Reduced GMII (RGMII) or embedded clock Serial GMII (SGMII). It interfaces directly to twisted pair media through an external transformer. The DP83867 is designed for easy implementation of 10/100/1000 Mbps Ethernet LANs. Optimized for ESD protection, the DP83867 exceeds 8-kV IEC 6 (direct contact). The DP83867 device is a robust, low power, fully featured Physical Layer transceiver with integrated PMD sublayers to support 10BASE-Te, 100BASE-TX and 1000BASE-T Ethernet protocols. Configurable I/O voltage (3.3 V, 2.5 V, 1.8 V).Fully compatible to IEEE 802.3 10BASE-Te, 100BASE-TX, and 1000BASE-T Specification.Start of Frame Detect for IEEE 1588 time stamp.
